Description
FEATURES
- 3-axis mechanism for flexible ceiling and wall-mount installation
- Lens Rotate 145°
- VerticaTilt 26.5°
- HorizontaPan 358°
- MicroSD card support (up to 64GB) for video storage
- External alarm I/O device connection
- POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs
- ONVIF standard supported to simplify system integration
- CrystaImage IP camera series provides higher compression ratio, and clearer & sharper images than other 2MP IP cameras, allowing high quality video storage with smaller storage capacity
- New IR technology adapted to enhance brightness at night as welas the effective distance of up to 15 meters
- Remote Surveillance
- Fully compatible with iOS and Android devices, and Internet Explorer on Windows operating system
- Push Video available on your iOS and Android devices when used with Push Video NVR series
SPECIFICATIONS
Network |
|
| LAN Port |
YES |
| LAN Speed |
10/100 Based-T Ethernet |
| Supported Protocols | DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS, SNMP |
| ONVIF Compatible |
YES (Profile S) |
| Number of Online Users |
10 |
| Security | (1) Multiple user access levels with password (2) IP address filtering (3) Digest authentication |
| Remote Access | (1) Internet Explorer on Windows operating system (2) 16CH Video Viewer on Windows & MAC operating system (3) EagleEyes on iPhone, iPad & Android mobile devices |
Video |
|
| Network Compression |
H.264 (Main Profile) / MJPEG |
| Video Resolution | 1920 x 1080 / 1280 x 720 / 720 x 480 / 352 x 240 |
| Frame Rate |
30fps |
| Multiple Video Streaming |
4 (H.264, MJPEG) |
General |
|
| Image Sensor | 1/2.9″ SONY CMOS image sensor |
| Min Illumination | 0.1 Lux / F1.5, 0 Lux (IR LED ON) |
| Shutter Speed |
1/7.5 to 1/8000 sec |
| S/N Ratio |
More than 48dB (AGC off) |
| Lens |
f3.8mm / F1.5 |
| Viewing Angle | 73.2° (Horizontal) / 42.8° (Vertical) / 83.2° (Diagonal) |
| IR LED |
1 Unit |
| IR Effective Distance |
Up to 15 meters |
| PIR Sensor | Detection Range 76° wide angle with up to 6m long distance at 2.5m height (under 30℃) |
| IR Shift |
YES |
| Smart Light Control |
YES |
| White Balance |
ATW |
| AGC |
Auto |
| IRIS Mode |
AES |
| DWDR |
YES |
| POE |
YES (IEEE 802.3af) |
| External Alarm I/O |
YES (1 input / 1 output) |
| RAM |
20MB |
| MicroSD Card Slot |
YES (up to 64GB) |
| Operating Temperature |
0℃ ~ 40℃ |
| Operating Humidity | Less than 60% relative humidity |
| Power Source (±10%) |
12V / 1A |
| Current Consumption (±10%) |
356mA |
| Power Consumption (±10%) | PoE: 6.5W max; PoN: 6.5W max; DC Adapter: 5.13W max |
| Net Weight (Kg) |
0.65 |
Audio |
|
| Line in |
YES (Mono) |
| Line out |
YES (Mono) |
Others |
|
| Mobile Surveillance |
iOS & Android mobile devices |
| Event Notification |
FTP / Email / SMS |
| 3-Axis |
YES |
| Digital Pan / Tilt / Zoom |
YES |
| Motion Detection |
YES |
| RTC (real-time clock) |
YES |
|
Minimum Web Browsing Requirements |
|
*The specifications are subject to change without notice.
